Conductor: Plain annealed copper stranded as per class 5 of IEC 60228, ISIRI 3084
Insulation: Polyvinyl chloride- PVC
Core identification: colour
Inner covering: Extruded PVC compatible with the operating temprature of the conductor, this inner covering is applicable to cables having conductor of 25 mm2 and above.
Outer sheath: Polyvinyl chloride- PVC
standard colour is black, but any other colour can be supplied on request.
Temperature: -30C to +70C
Maximum short circuit temperature: 150C (5 seconds Max.)
Working voltage: 0.6/1.0 kv
Conductor resistance: As per class 5 of IEC 60228
Test Voltage: 3.5 kv rms or 8.4kvdc for 5 minutes
Flame retardant: Acc. IEC 60332-1
